COPPER Solutions

C6 unshielded patchcords

Eurolan Category 6 unshielded is a halogenfree (LSZH) patchcord.
Characterised up to 250 MHz Completes the Ethernet protocol 10Mb, 100Mb Gigabit Ethernet. Follows the RoHS directives and have molded connectors
Delivered piece packed in pinpack
Complies with the specifications according to ISO/IEC 11801 EN 50173-1:2011 ANSI/TIA-568-C.2:2009 IEC 60332-1

downloads

For orderinginformation of other colours than white, please se document under DOWNLOADS

Ordering information

E-number
5153145
5153146
5153147
5153148
5153149
5153150
5153151
5153152
5153153

Part number
21D-U6-0EWT
21D-U6-01WT
21D-U6-02WT
21D-U6-03WT
21D-U6-05WT
21D-U6-07EWT
21D-U6-10WT
21D-U6-15WT
21D-U6-20WT

Description
Eurolan RJ45-RJ45 LSZH C6 UTP 0,5m white
Eurolan RJ45-RJ45 LSZH C6 UTP 1m white
Eurolan RJ45-RJ45 LSZH C6 UTP 2m white
Eurolan RJ45-RJ45 LSZH C6 UTP 3m white
Eurolan RJ45-RJ45 LSZH C6 UTP 5m white
Eurolan RJ45-RJ45 LSZH C6 UTP 7,5m white
Eurolan RJ45-RJ45 LSZH C6 UTP 10m white
Eurolan RJ45-RJ45 LSZH C6 UTP 15m white
Eurolan RJ45-RJ45 LSZH C6 UTP 20m white

C6 unshielded slim patchcords

Eurolan Home Slim patch cord is made by a flat cable for saving space.
Outer sheat is PVC.
Characterised up to 250 MHz Completes the Ethernet protocol 10Mb, 100Mb Gigabit Ethernet.
Delivered piece packed in pinpack.


downloads

Ordering information

E-number
5169817
5169818
5169836
5169837

Part number
50S-60-0CWT
50S-60-0EWT
50S-60-01WT
50S-60-02WT

Description
Eurolan Home C6 slim 0,3m white
Eurolan Home C6 slim 0,5m white
Eurolan Home C6 slim 1m white
Eurolan Home C6 slim 2m white

C6 shielded patchcords

Eurolan Category 6 shielded is a halogenfree (LSZH) patchcord.
Characterised up to 250 MHz Completes the Ethernet protocol 10Mb, 100Mb Gigabit Ethernet. Follows the RoHS directives and have molded connectors
Delivered piece packed in pinpack
Complies with the specifications according to ISO/IEC 11801 EN 50173-1:2011 ANSI/TIA-568-C.2:2009 IEC 60332-1

downloads

For orderinginformation of other colours than white, please se document under DOWNLOADS

Ordering information

E-number
5153245
5153246
5153247
5153248
5153249
5153250
5153251
5153252
5153253

Part number
21D-S6-0EWT
21D-S6-01WT
21D-S6-02WT
21D-S6-03WT
21D-S6-05WT
21D-S6-7EWT
21D-S6-10WT
21D-S6-15WT
21D-S6-20WT

Description
Eurolan RJ45-RJ45 LSZH C6 SF/UTP 0,5m white
Eurolan RJ45-RJ45 LSZH C6 SF/UTP 1m white
Eurolan RJ45-RJ45 LSZH C6 SF/UTP 2m white
Eurolan RJ45-RJ45 LSZH C6 SF/UTP 3m white
Eurolan RJ45-RJ45 LSZH C6 SF/UTP 5m white
Eurolan RJ45-RJ45 LSZH C6 SF/UTP 7,5m white
Eurolan RJ45-RJ45 LSZH C6 SF/UTP 10m white
Eurolan RJ45-RJ45 LSZH C6 SF/UTP 15m white
Eurolan RJ45-RJ45 LSZH C6 SF/UTP 20m white

C6a unshielded patchcords

Eurolan Category 6 unshielded is a halogenfree (LSZH) patchcord.
Characterised up to 500 MHz Completes the Ethernet protocol 10Mb, 100Mb, 1000Mb Gigabit Ethernet.
Follows the RoHS directives and have molded connectors.
Delivered piece packed in pinpack

downloads

Ordering information

E-number
5151540
5151546
5151548
5151549
5151550
5151551
5151556
5151557

Part number
21D-UA-0EWT
21D-UA-01WT
21D-UA-01EWT
21D-UA-02WT
21D-UA-03WT
21D-UA-05WT
21D-UA-07WT
21D-UA-10WT


Description
Eurolan RJ45-RJ45 LSZH C6A UTP 0,5m white
Eurolan RJ45-RJ45 LSZH C6A UTP 1m white
Eurolan RJ45-RJ45 LSZH C6A UTP 1,5m white
Eurolan RJ45-RJ45 LSZH C6A UTP 2m white
Eurolan RJ45-RJ45 LSZH C6A UTP 3m white
Eurolan RJ45-RJ45 LSZH C6A UTP 5m white
Eurolan RJ45-RJ45 LSZH C6A UTP 7m white
Eurolan RJ45-RJ45 LSZH C6A UTP 10m white

C6a shielded patchcords

Eurolan Category 6 shielded is a halogenfree (LSZH) patchcord.
Characterised up to 500 MHz Completes the Ethernet protocol 10Mb, 100Mb, 1000Mb Gigabit Ethernet.
Follows the RoHS directives and have molded connectors.
Delivered piece packed in pinpack
Complies with the specifications according to ISO/IEC 11801:2011 (Ed.2.2), EN501731:2011, EN 50173-2:2007 incl. Amendment A1:2010, ANSI/TIA-568-C.2:2009, IEC 61935-2:2010 (Ed. 3.0) (transmission requirements)

Ordering information

E-number
5153280
5153281
5153282
5153283
5153284
5153285
5153286
5153287

Part number
21D-SA-0EWT
21D-SA-01WT
21D-SA-1EWT
21D-SA-02WT
21D-SA-03WT
21D-SA-05WT
21D-SA-7EWT
21D-SA-10WT

Description
Eurolan RJ45-RJ45 LSZH C6A S/FTP 0,5m white
Eurolan RJ45-RJ45 LSZH C6A S/FTP 1m white
Eurolan RJ45-RJ45 LSZH C6A S/FTP 1,5m white
Eurolan RJ45-RJ45 LSZH C6A S/FTP 2m white
Eurolan RJ45-RJ45 LSZH C6A S/FTP 3m white
Eurolan RJ45-RJ45 LSZH C6A S/FTP 5m white
Eurolan RJ45-RJ45 LSZH C6A S/FTP 7,5m white
Eurolan RJ45-RJ45 LSZH C6A S/FTP 10m white

C6 unshielded adapter Patchcord

Eurolan Adapter-Patch cords are used for a connection of a CP=Consolidation point.
The Adapter Patch cords are complete with Keystone-RJ45.
U/UTP Adapter Patch cords are made by solid copper and have a flame retardant jacket.
The U/UTP cable is verified for 250MHz.

downloads

Ordering information

E-number
5153083
5153084
5153085

Part number
23D-U6-7EWT
23D-U6-10WT
23D-U6-15WT

Description
Eurolan Patchcord C6 U/UTP solid RJ45-Keystone 7,5m
Eurolan Patchcord C6 U/UTP solid RJ45-Keystone 10m
Eurolan Patchcord C6 U/UTP solid RJ45-Keystone 15m

C6a shielded adapter Patchcord

Eurolan Adapter-Patch cords are used for a connection of a CP=Consolidation point.
The Adapter Patch cords are complete with Keystone-RJ45.
Cable is C6A S/FTP stranded and have flame retardant LSZH jacket. The cable is verified up
to 500MHz.

downloads

Ordering information

E-number
5153080
5153081
5153082


Part number
23D-SA-7EWT
23D-SA-10WT
23D-SA-15WT

Description
Eurolan Patchcord C6A S/FTP RJ45-Keystone 7,5m
Eurolan Patchcord C6A S/FTP RJ45-Keystone 10m
Eurolan Patchcord C6A S/FTP RJ45-Keystone 15m
