COPPER Solutions

C6a utp Cable

Eurolan Category 6A UTP is a halogenfree (LSZH) distribution network cable.
The cable is verified to 500 MHz bandwith (10Gbit Ethernet).

Complies with the specifications according to EIA/TIA 568-C.1; ISO/IEC 11801 2nd ed; IEC 61156-5; EN 50173; EN 50288-11-1; IEEE 802.3at.
Supports ethernet protocols: 10Mbit/100Mibit/1000Mbit/10000Mbit (10Gbit).

downloads

19D-UA-DCA-500 NY.pdf 689 KB

19D-UA-22xx.pdf 100 KB

ZB-1001 19D-UA-DCA-R500WT E-no 4902005E.pdf 280 KB

European RoHs directive Eurolan 2016.pdf 69 KB

SundaHus Miljödatablad 19C-UA-DCA-R500WT.pdf 110 KB

Ordering information

E-number
4902005

Part number
19C-UA-DCA-R500WT

Description
Eurolan C6a 4pair U/UTP LSZH White DCA 500m/reel

C6a utp Keystone jack

Eurolan Keystone C6A comes in a version where termination is made by IDC 110 tool or Eurolan Quick tool.
Verified to 500 MHz and manage applications up to 10 Gbit.
Complies with the specifications according to ISO/IEC 11801:2011 (Ed 2.2) ; IEC 60603-7-41:2010; IEC 60512-99-001:2012 (Ed. 1.0) EN 50173-1:2011; EN 50173-2:2007 incl amendm. A1:2010; ANSI/TIA-568-C.2:2009.
Supports ethernet protocols: 10Mbit/100Mibit/1000Mbit/10000Mbit (10Gbit).

downloads

16B-UA-03XX NY.pdf 511 KB

Instructionsheet 16B-UA-03XX.pdf 613 KB

16B-UA-03XX 2023-319 EUROLAN.pdf 338 KB

SundaHus Miljödatablad 16B-UA-03WT.pdf 123 KB

Ordering information

E-number
5140252
5140370
5140447
5140448

Part number
16B-UA-03WT
16B-UA-03BL
16B-UA-09SL-WT
16B-UA-09SL-WT-24

Description
Eurolan Keystone Cat 6a UTP Q-toolready, white
Eurolan Keystone Cat 6a UTP Q-toolready, black
Eurolan Keystone RJ45 Toolless shuttered C6A UTP
Eurolan Keystone RJ45 Toolless shuttered C6A UTP 24p

C6a utp Keystone tooless jack

Eurolan Cat 6A jack has standard keystone hole pattern with 90 degree output for termination terminals. The device is built with an extra plastic protection on the inner wall to avoid possible short circuits. Toolless which connects without special tools. Integrated inward shutter. The jacket is specified for frequencies up to 500 MHz. Meets the requirements according to ISO/IEC 11801-1, Category 6A, IEC 60603-7-41. ANSI/TIA-568.2D, Category 6A. PoE (Power over Ethernet) 100W Level 8 according to IEC 60512-99-002. Type 4.

Instructionsheet 16B-UA-09SL-WT.pdf 1.1 MB

16B-UA-09SL-WT NY.pdf 460 KB

Ordering information

E-number
5140447
5140448

Part number
16B-UA-09SL-WT
16B-UA-09SL-WT-24

Description
Eurolan Keystone RJ45 Toolless shuttered C6A UTP
Eurolan Keystone RJ45 Toolless shuttered C6A UTP 24p

C6a utp Patchpanel, unLoaded for keystone

19” patchpanel 24 port with Eurolan keystone footprint.
The panel is built in black painted steel.
1 HE.
Cable striping organizer is included as well as marking list for 24 ports.
